Sector: RACING
Design No. 360
PAX NZL
43ft IMS Cruiser/Racer
Length13.06m / 43.19′
Design Year1995
BuilderCookson Boats
Description
Design 360 is a 43ft IMS Cruiser/Racer PAX NZL designed by Farr Yacht Design in 1995. She has an overall length of 43.19 feet.
Visual Assets
Technical Specifications
| Year | 1995 |
| Type | Racing Yacht |
| Rule | IMS |
| LOA | 13.06 m43.19 ft |
| Beam | 3.99 m13.09 ft |
| DWL | 11.24 m36.88 ft |
| Draft | 2.82 m9.25 ft |
| Displacement | 6,490 kg14,310 lbs |
| Ballast | 3,665 kg8,080 lbs |
| Headsail Hoist (I) | 15.8 m51.84 ft |
| Foretriangle Base (J) | 4.73 m15.52 ft |
| Main Hoist (P) | 17.02 m55.84 ft |
| Main Foot (E) | 6.24 m20.47 ft |
Technical Resources
Free downloads — no account required.
Design Plans
Available on requestOriginal design drawings from the Farr archive. Pricing is being finalized — contact us for availability or join the waitlist.
21 original drawings in this plan set
2D CADNative CAD plans available.
Interested in a Farr design?
Whether you’re looking for plans, consulting, or a new project — let’s talk.
Designer’s Notes
Design #360 43' IMS Cruiser/Racer December 1995 After watching the Farr designed IMS 43 FLASH GORDON 2 achieve much success on the racing circuit, Jim Farmer of New Zealand expressed interest in building an IMS Cruiser/Racer version that would not be appreciably slower than its pure racing equivalent, but have reasonable cruising comforts and facilities. The IMS 43's hull shape was modified from previous designs as a result of ongoing IMS research and to be entered into the 1995-96 racing circuit. The drawings are for a one off custom construction made of Kevlar and E-glass with foam core sandwich which provides an inexpensive, high tech solution. Additionally, the internal structure and bulkheads meet the minimum panel weight requirements of the current IMS rule. A new deck layout more than complies with current IMS cruiser/racer regulations and is actually more suited to this client's
