FARR 41/PHASE 4
40ft Cruising Yacht
Description
Design 178 is a 40ft Cruising Yacht FARR 41/PHASE 4 designed by Farr Yacht Design in 1986. She has an overall length of 40.0 feet. The Farr Phase 4 is an exceptional, pedigreed cruiser-racer that successfully satisfies the difficult brief of being both a fast, rewarding sailboat and a comfortable three-cabin cruiser. It is best suited for discerning sailors who value sailing feel, speed, and build quality over the cavernous, caravan-like interiors of modern, wide-stern cruising designs.
Visual Assets
Technical Specifications
| Year | 1986 |
| Type | Cruising Yacht |
| LOA | 11.74 m38.52 ft |
| Beam | 3.81 m12.5 ft |
| LWL | 9.86 m32.35 ft |
| Draft | 1.78 m5.84 ft |
| Displacement | 5,838 kg12,843 lbs |
| Ballast | 2,223 kg4,900 lbs |
| Keel Type | Bulb |
| Hull Construction | Fiberglass |
| Headsail Hoist (I) | 14.34 m47.05 ft |
| Foretriangle Base (J) | 4.14 m13.59 ft |
| Main Hoist (P) | 12.52 m41.07 ft |
| Main Foot (E) | 5.01 m16.43 ft |
| Rig Type | Sloop |
Technical Resources
Free downloads — no account required.
Design Plans
AvailableOriginal design drawings from the Farr archive, sold by the sheet as PDF downloads. Choose only the drawings you want.
4 drawings available · $150 per drawing
HAND DRAWNCopies are high-resolution PDF copies of hand-drawn plans.
Interested in a Farr design?
Whether you’re looking for plans, consulting, or a new project — let’s talk.
Designer’s Notes
Introduced in 1988, the Farr Phase 4 represents a sophisticated, lateclassic collaboration between legendary naval architect Bruce Farr and premium Australian boat builders. Officially designated as Design 178 in the Farr Yacht Design archives, this 39foot cruiserracer was engineered to bridge the gap between grand prix performance and comfortable, longdistance family cruising. Built primarily by Binks Yacht Constructions—a yard legendary in Australian maritime history for its pioneering fiberglass layups and exceptional structural standards—with some hulls completed or finished by Whitsunday Coast Yacht Constructions, the Phase 4 was conceived as an elegant alternative to the highvolume, massproduction imports of the era. Rather than compromising sailing characteristics for cabin space, the design prioritizes a slippery, easily driven hull form that remains fast, balanced, and highly competitive in twilight club racing, while providing a seaworthy, liveaboardcapable home.
